GL8.4 is a multipurpose, high-output forwarder with a powerful, economical 160hp DEUTZ 4-cylinder engine that meets the latest emission standards (Tier 4 final). This gives the GL8.4 plenty of power for unrivalled harvesting capacity. Coupled with POCLAIN's latest-generation wheel motors, they give you increased maximum clearance (up to 28%), guaranteeing a high-performance, efficient transmission. To optimise fuel consumption and noise levels, GL8.4 automatically adapts its engine speed according to need.
GL8.4 is equipped with the largest cab on the market. GREGOIRE has designed it’s cab with special care, focusing on a large working space, wide screen surface, upgraded soundproofing, reinforced safety and driver ergonomics. To ease access to the cab a single press on the outside opening switch will slide out the inclined ladder, turn the cab door sill light on and start the i-Monitor screen. To use the machine to its full potential GL8.4 integrate the latest easy-to-use technology : a i-Monitor touch screen (12”), Data storage, Headland sequencing, a fully customizable joystick with all machine functions and an exclusive transmission management. Connected harvest. Because growers today need more data to make the right decision GL8.4 can be equipped with the newest technology : NEOtrack, NEOmap and NEOmass
The latest GREGOIRE picking head ARC2 allow a quick and perfect pick with the best care for your vines. AUTOpinch combined with a double pendulum picking system ensure you a perfect flexibility and adaptability whatever the vineyard conditions. The pneumatic catcher tray guarantee a perfect water tightness and the adjustable rail pressure to minimize impacts on young plants. Harvest cleaning is operate by 2 bottom fans and 2 top fans or the new EASYclean sorting system. To reduce dumping time and increase productivity GL8.4 are fitted with two lateral stainless steel bins of 2000L or 1500L
Access & Maintenance Because regular maintenance means an uninterrupted harvest; from the very beginning GL8.4 has been designed to make every cleaning and maintenance operation easy. To make those operations easier GL8.4 has a large available space inside the picking tunnel, a simple working cinematic and an oversized upper platform. To save time and water GL8.4 also integrate a washing line that directly provide water to the top platform and a separate control box that gives you access to harvest function without having to enter the cab. Top deck that runs from the back to the front of the machine gives total freedom of movement to proceed maintenance, settings and access to centralized grease-points Like all former models of the range GL8.4 end of season works (washing & maintenance) are fast and minimal
GL8.4 tractor base can be equipped with front canopy management tools and multi-row sprayers. Automatic tool recognition using ISObus technology. Tools and sprayers are directly controlled by the harvester touchscreen and joystick. Coupling and uncoupling of multifunction tools is simple and quick using the centralized electric and hydraulic connections. GL8.4 tractor base is the perfect compromise between productivity, power, and manoeuvrability. Quick and efficient it suit all vineyard condition from 1.7-meter row
AUTOdrive
AUTOdrive automatically adapts the engine speed to the ground speed when driving. This integrated management of the engine speed gives the transmission unrivalled flexibility and significantly reduces both consumption and the noise level. The joystick can also be used as a forward drive control.
AUTOspeed
AUTOspeed is used to perfectly regulate the working speed, regardless of the terrain. It is simple to activate via an easily accessible button on the joystick, allowing you to return quickly to the programmed speed.
TOOLintegration
With TOOLintegration, GREGOIRE versatile carriers are pre-equipped as standard to be versatile, allowing a GREGOIRE spraying unit or tool to be easily installed. ISOBUS technology allows this equipment to be controlled directly using the existing controls in the cab.
ARC system
The ARC system harvesting principle ensures high quality harvesting and as yet unrivalled handling of the vine. Its exclusive characteristics give you access to an unlimited range of settings, which translates into quick and easy adaptation to any type of vineyard.
TEP
TEP, the train of pneumatic sealing scales (GREGOIRE patented), perfectly adapts the recall force of the sealing scales to the different types of vine. By adjusting the air pressure in a membrane located underneath the scales, vines can be handled as delicately as possible whilst limiting losses on the ground.
EASYclean
On board sorting system allowing perfect harvest quality. The « sorting head's » oscillating motion separates the grapes from vegetal materials. The grapes are stocked in the bins and the vegetal materials are expelled via the sorting table.Ample access available for maintenance.
Class 4 Cab
New generation cabin. External dusts, aerosol, and steam filtration. Built for optimum user safety and comfort. Technical data: active carbon filter, 30m³/h new air flow, 20 Pa pressurization, pressure control indicator in cabin.
Fiche technique
GL8.4
For plantations / vineyards |
Vine width from 1,70 m
Height of 1.95m underneath the chassis
|
Engine or linkage |
Motore DEUTZ (Stage V)
4 x 4,1 l cylinders
Delivers 160 hp (115 kW) at 2 100 rpm
Maximal torque 609 nm a 1 600 rpm
Automatic rpm management
Fuel tank capacity 260 l
AdBlue® tank capacity 20 l
|
Transmission |
Speed management from the joystick (impulse + linear position + approach mode)
Hydrostatic transmisison Twin Lock 4 wheels drive
Automatic anti-spinning Front/Rear (torque distributor)
AUTOspeed : cruise control
Optimisation du AUTOdrive, Automatic rpm optimization system on road and work mode
Max. road speed (for autorized countries only)with 4 wheels drive : 30 km/h / 18,6 mph
Oil tank capacity : 110 l
Filtration : Pressure + return
Elevation / slope correction : 600 mm / 28%
AUTOlevel
Stearing radius 4,00 m
EASYturn (option): steering wheels revolution reduction
EASYpilot (option) Automatic row following system with 3D cameras (EasyTurn needed)
Front tires 380/85R24
Rear tires 480/70 R28
|
Driving and control |
Central cab
Cab volum 2,2 m3
Cab glazed surface 5 m2
Automatic, reversible air co and cooling compartment
Pneumatic seat great comfort
ROPS & CAT 4 driver protection(dust, aerosol and fumes) (option)
Radio Bluetooth handsfree
2 USB plugs
Steering wheel column with height adjustment and 2 pivots
Touch and color 12" screen i-Monitor
Joystick Lateral browsing adjustment wheel + shortcuts
Multifunction and ergonomic joystick with backlighting
Nominatives records (hours, hectares, ...) with USB extraction
Nominatives settings with USB extraction
2 color cameras
EASY 360 (option) : 360° cameras (broadcasted on additional screen)
Laterale ladder (25°) with automatically slide
10 lights (LED)
Lighting power : 18 160 lumens
|
Harvesting module |
Double pendulum system (shacking + conveying)
Automatic lock activating road mode
Suspended picking head : 8 silent-blok
14 shakers ARC² with fast fixing FASTfit
AUTOpinch : automatic and continue pinch setting management(option)
2 x 21 scales
Pneumatic catcher tray
Catcher tray length 2 600 mm
Minimum harvesting height less than 15 cm
Belts width 320 mm
Tunnel width 650 mm
Belts hydraulicaly driven with adjustable speed and reverse
Picking function with low speed alarms
Centralized greasing
Oversize top platform
Separated control box
Integrated washing line with water supplying on top platform
|
Cleaning |
2 bottom fans
2 vertical extractors
2 dead wood deflector
2 2 top fans
EASYclean - sorting system with oscillating fingers (option)
|
Bins |
Stainless steel bins 1 500 l (option)
Large stainless steel bins 2 000 l
Emptying height : 2 985 mm
Bin level sensor on i-Monitor
Automatic bins filling by feeder screw
|
Multipurpose |
TOOLintegration
Removable harvesting assembly
Quick harvesting modul mounting
Front tool holdder (option)
ISOBUS technology
|
